Networking

Network Ports


TCP
21	ftp
22	ssh
23	telnet
6642	TIPCO Spotfire Pro Server
8111	Isentris application server (main web gui used in URL)
8405	Isentris admin

23221	Isentris back end server

UDP

Network technologies, standards, info.


802.3ad		IEEE standard for link aggregation, replacing old proprietary protocol
		such as Cisco EtherChannel which req same brand fn.
		Provides more bandwidth and redundancy.  1999.

802.3af		Power over Ethernet (existing cat 5) over 4 wires.
		48 V AC, 350 mA, 12.95 Watts.
		Contain detection mechanism, only equip w/ signature auth will get power,
		thus safe for mixing old and new equip.

802.1q		aka dot1q.  VLAN Tagging.

802.11		WiFi. b=11 Mbps, a=55 in new freq, g=11/55 in same freq of b.  n=110

looseends


List different configuration files that need to be updated when moving machine from one ip/subnet to another.


solaris:

/etc/hostname.hme0	{name or ip}
/etc/nodename
/etc/inet/hosts
/etc/inet/netmasks
	172.27.4.0	255.255.252.0	# fffffc00 quad class C .4, .5, .6 + .7
					# broadcast is 172.27.7.255
	172.27.28.0	255.255.255.0	# normal class C.

/etc/resolv.conf
/etc/nsswitch.conf

/etc/defaultrouter
/etc/defaultdomain	{used to set domainname for NIS domain name}
/var/yp/binding/`domainname`/ypservers	{bind use this to find list of NIS servers}

note that a damn system that uses NIS, but don't have network setup properly,
will have issues at boot time as NIS hangs boot process.   it is before even inetd starts,
so can't even telnet in (normally, start NIS so that telnet can authenticate NIS users).


Switch Port Tech


Port	Speed	Technology	SERDES lane 	Cable plug type
------	-------	--------------	-------------	---------------
gbic?	1-10G	very old now			SC-SC
sfp
sfp+	10G	10G ethernet			LC-LC

	 	SDR
	 	DDR
qsfp+?	 40G	QDR		4x10 Gbps
qsfp2?	 56G	FDR
qsfp28	100G	HDR100, EDR	4x25 Gbps	MTP aka MPO
qsfp56	200G	HDR200		4x50 Gbps

qsfp are wider than sfp ports, but not 4x as wide, at least not physically :P


NOTE:
Each cycle at 1 GHz takes 1 ns
It takes about 1 ns for light in vacum to travel 1 foot.


MMF = MultiMode  Fiber -   only    for SR short range (distance), eg up to ~100m.  Cheaper optics and cables.  eg 850nm wavelegth.
SMF = SingleMode Fiber - typically for LR long  range (distance). eg km.  LR4 carry multiple 4 wavelegths thus serve multiple SERDES lane on single fiber. eg 1310nm, 1305,1301,1296nm.

fiber 	type	color	typical use
----  	----	-------	--------------------
OM2  	MMF?	orange	 56 Gbps? FDR
OM3 	MMF? 	aqua	100 Gbps  EDR
OM4 	MMF? 	magenta	200 Gbps  HDR200

OM4?	SMF?	orange	100 Gbps?

Ref:
  • Understanding 100G Transceiver Transmission Principles
  • Difference between QSFP+ SingleMode vs MultiMode
  • Cisco


    config term
      interface fa0/37
      no shutdown

      spanning-tree portfast	# immediate enable port, run spanning tree later.

    Implications:
    If a switch is plugged into a port that is not pre configured to allow spanning tree,
    it will be blocked, and not even link light will come up.
    'no shutdown' will free up the port for use again.
    spanning-tree fast port, or something like that, enables the spanning tree alg on that port,
    thus allowing the switch to be cascaded.

    --

    show running-config interface gi6/48	! see config for specific interface



    show running-config vlan   ! see list of avail vlan, no ports
    show vlan brief		   ! list all vlan and its member ports
    show vlan id 1		   ! show only info for vlan 1

    show interfaces port-channel 2
    show etherchannel    summary		! (P) means port is up as part of port-channel
    show etherchannel 13 summary

    show etherchannel port-channel
    show int port-channel 14

    ! when looking at running-config
    ! etherchannel are setup without any port listing
    ! search for port-group PO#  under each interface definition to see
    ! what ports are in a given ether-channel.


    show inter status 	! auto/half/100/etc info
    show inter status | include a-10 	! include is similar to grep but more exact match.

    show inter accountin			! statistics, pkg in/out count.

    show interface stat
    show interface counters


    show mac-address-table int gi5/12	! mac seen on specific port
    sh ip arp		   	   ! find mac and pair up with IP
    				   ! need to run in L3 (router) to have IP info.


    show mac-address-table dynamic vlan 30	! list all mac address fwd table.
    					! not sure what fwd means...
    show mac-address-table dynamic | include Fa0/9	! get mac address on putter on the specified port



    --
    clear arp			! clean all arp entries
    				! no way to erase single ip/arp entry

    logging console			! get alert when things change
    				! how?



    Cisco MDS SAN switch

    Cisco MDS 9124 Fibre Channel switch.
    Cisco MDS 9222i FCIP switch.


    show terminal           		# display term char
    terminal length 0       		# disable --more-- paging

    terminal session-timeout 0		# expect this to disable auto logout, but then take out "callhome" from running-config
    terminal session-timeout 525600		# set to max allowed timeout, no changing "callhome" from running-config

    show tech-support details               # grab tons of info
    show tech-support details create        # suppose to prompt for ftp server to put output info to


    show running-config diff		# see changes that are not saved to startup yet
    show accounting log			# show a log of changes made on the switch, good to find vsan config changes, etc.



    copy running-config startup-config	# save run time config to permanent config store
    config term				# get into config mode using terminal
    do (cmd)				# run exec mode command while in config mode.


    show interface brief			# see which port is up, what VSAN it is assigned to, etc
    show interface fc1/4			# see all info about port, but not wwn of dev connected to it.
    show int mgmt 0				# find IP assigned to the device

    show fcs database			# see wwn of attached devices (sort by vsan, interface)
    show fcs database vsan 300		# for specific vsan (instead of all)

    show flogi database			# similar to "fcs" above, good in telling vsan assignment problem.



    show device-alias database		# list attached-pWWN wwn to name map database
    show device-alias pending		# list what will become live once commit will run
    show device-alias pending-diff		# diff b/w live database and pending

    show zone
    show zoneset				# display zone info in slightly diff format that show running-conf
    show zoneset active			# any pwwn that is not active has missing * in the front, good to spot problem!
    show vsan				# list all vsan and which port is assigned to which vsan
    show wwn ...				# wwn info for switch/port internal wwn


    show cli alias				# list command aliases


    GUI tool.
    http://switch-mgnt-ip
    download java program.
    - device manager: control port, link status, etc.  login directly to the switch using switch username credentials.
    - fabric manager: control zoning info.  login to localhost, admin/password,
      then discover the switch by entering its IP, and username+password that is
      in the switch.



    Sample zoning addition command

    EMC recommended best practice is one initator and one terminator per zone. In practice I found placing both terminator of the Clariion on the same zone to have no adverse effect and make for smaller list of zones.
    One host for each zone. Even in a cluster access environment, zoning does not include multiple host. Storage group configurtaion in Navishere provides LUN access to multiple hosts.

    ! (config term)
    device-alias database
      device-alias name JAWS3_HBA1 pwwn 10:00:00:00:c9:5f:2e:95
            ! pwwn can be found from "show fcs database" under attached-pWWNs
            ! pwwn match "PortName" in FLOGI tab of GUI
      exit

            ! (do) show device-alias pending-diff
            !       ! will show new entry as not commited (live?) yet

      device-alias commit

    ! zoning is done per wwn of the attached devices
    ! not the physical port number of the switch
    zone name JAWS3_HBA1-cX3_1828_SPB1 vsan 30
            member device-alias JAWS3_HBA1
            member device-alias CX3_1828_SPB1
            exit

            ! show running-config will translate above to
                    zone name JAWS3_HBA1-cX3_1824_SPB1 vsan 30
                        member pwwn 10:00:00:00:c9:5f:2e:95
                    !               [JAWS3_HBA1]
                        member pwwn 50:06:01:69:41:e0:7b:37
                    !               [CX3_1828_SPB1]


    zoneset name vsan30_prod vsan 30
            member JAWS3_HBA1-cX3_1824_SPB1
            ! above will add member, not replace any existing
            ! to remove, use "no member"


    zoneset activate name vsan30_prod vsan 30
    !  activation IS needed !!
    !  can be verified by "show zoneset active"



    !  add the same host with the alternate SP :
    zone name JAWS3_HBA1-cX3_1828_SPA3 vsan 30
            member device-alias JAWS3_HBA1
            member device-alias CX3_1828_SPA3
    zoneset name vsan30_prod vsan 30
            member JAWS3_HBA1-cX3_1828_SPA3
    zoneset activate name vsan30_prod vsan 30



    copy running-config startup-config


    Changing a specific port's vsan membership.
    In addition to definining zoning info, the switch port that a host is plugged into need to have its VSAN defined, or else data won't flow thur it!

    ! (config term)
    vsan database
      vsan 30 interface fc1/2
      vsan 30 interface fc1/3
      vsan 50 interface fc2/2
      vsan 50 interface fc2/3
      ! etc...
      exit

    ! show flogi database
    ! is a good way to see if a swich port (host node) is in the desired vsan.

    ! show interface brief
    ! should list all switch ports and which VSAN they belongs to.
    ! no assignment will default to VSAN 1


    Cascaded (ISL Linked) Switches

    In a cascaded switch environment, Inter Switch Link (ISL) can be used to daisy chain the switches. Port Trunking can be used, and all VSANs data would be carried on this trunk if it is not explicitly coded to do certain VSAN.
    One switch would act as the "main" and would usually get all the config. All zone config should be done on the primary, and when downstream switch come online, they will read such config. Downstream switch would have some basic info specific to them. eg Port VSAN config would be on each switch.
    One piece that I am still no clear is that, ISL linked switch exchange zone config info. A copy running-config startup-config would write down such config on both switches. When one issue commands to remove zoning info, it will probably mean doing the copy run start on both switches, less the partner has some old info and re-add such info to the runnig-config when it reboots...
    To be safe, config should be saved on all switches, upstream and downstream.
    If downstream don't have any zoning config at all, then it is fine and when it reload, it will get the info from the upstream switch. But in a failure scenario, it seems to work out better if each switch has the config. It also prevent other tool like ESRS making configs that diverges and create DB discrepancy when both swtiches reboot, creating a whole SAN zoning mess up. If the running config is the same on both switch and they reboot, then they will at least provide basic consistency.

    Config should be done on "principle" switch. But if there are NPIV switch involved, then zoning config should be done on the CORE NPIV switch, even if it is not the priciple swithc. Again, save running-config on all switches, check that there "show zoneset active" matches up on both switches!!
    Show fcs ie
    # Figuring out switch connectivity/topology, figure out switch's WWN
    # loc = switch command ran on
    # adj = peer switch (upstream/downstream not showed)



    Show fcdomain domain-list
    # see which one is principal (upstream) switch
    # each vsan has a principal swtich, though ISL linked swich, each one could be principal for diff vsan
    # zone config should be done on principal switch to avoid sync problems
    # but if NPIV is used, the zoning should be done on NPIV core switch even if it is not the principal for the vsan





    ---


    Show zone pending-diff
    # see what changes would take place when making a zoneset live

    Show zone status
    # see how many zones and zoneset are there, sync status with other switches



    clear zone database vsan
    # hopefully never need to use this
    # clear the (full zone database?) on a switch, not sure if it affect the linked switch (parent/child)


    Zoneset import interface fcX/Y vsan #
    # import (all?) zoneset from one switch to another
    # eg use after zone info has been cleared
    # or force direction of DB sync when two linked switch has out-of-sync DB.

    zoneset import interface port-channel # vsan #
    # altered form when ISL port channel is in use b/w linked switch
    # ISL can be "bonded" together to create port-channel, just like cisco ethernet switch





    Zone copy active-zoneset full-zoneset vsan #
    # copy the active zoneset into a "full-zoneset" db,
    # ie, creating the passive "full zoneset" db from the live current config
    # maybe needed if full-zoneset db is out of sync
    # but live running config from active zoneset is correct



    # bottom line
    # if the active zoneset on the ISL linked switch are the same
    # then config is stable
    # copy run start (on all switches) from this point would produce consistent result
    # (this should dump active zoneset config to config that will be loaded at boot)




    Non-ISL Linked / "Dumb" Access Gateway switch

    If the complexity is not overwhelming and Access Gateway (NPV+NPIV) mode can be used, this seems to be a much easier config than using ISL.
    ISL is good for large fabric interconnect that need multiple VSAN traffic, trunk port, etc.
    Access Gateway mode should be simple and efficient to add ports to connect more hosts or tape drives than is available from a single switch, and just need a simple extension to add more ports.

    Tech jargons:
    NPIV - allows switch to see multiple WWN on the same port w/o configuring ISL.
    NPV - kind of turn switch into "HBA mode", where multiple blades can be viewed as VM on the same server, and NPV mode switch port is viewed like an HBA port that presents multiple WWN to "upstream" switch. NPV is like emulating server.

    Brocade don't seems to emphasize the diff between NPIV and NPV. It calls the "dumed" switch in "Access Gateway" mode, so that no programming is done on it. It marely pass traffic and WWN to upstream/parent switch (the non-Access Gateway switch), which has all zoning info. This has benefits of saving Domain ID (limited to 16?), removing inter-vendor interoperability problem (because it does not need ISL config). The tech allows "merging" multiple physical switch into a single larger virtual switch with many more ports. See Access Gateway whitepaper for more details.

    eg In Dell blade chassis switch where multiple host is consolidated into a single physical port. In Access Gateway mode, the 4 WWN will show up, but the fc switch act transparently, so avoid the need to have an inter-switch link config, which could be quite painful when diff vendors switches are mixed. With Access Gateway mode, the zoning is all done by the smart switch, and the blade chassis switch is like "dummy" or transparent to all the config.

    Technically, E_Port are used to connect switches together. F_Ports are the port on the switch that HBA/host node connects to. N_Port is the port on the HBA card itself. Access Gateway essentially makes the switch in the blade chassis "disapear" from the logical view of the fabric config, and upstream switch will see N-port WWN connected to it when in fact it is connected to the Access Gateway switch. E_Port will not show up as ISL is not used.

    Essentially, the "smart" (upstream) switch is the NPIV switch, and the "dumb" (downstream, access gateway mode) switch is the NPV switch.
    If want to worry the difference between NPIV (N-port ID Virtualization) vs NPV (N-Port Virtualization), here are a couple of blogs explaining it:
    Config
    feature npiv		# enable the npiv feature (off by default in stand alone switch)

    Borcade switch that fit inside a blade chasis has Access Gateway config as default. If not, issue:
    siwtchMode access gateway mode

    need to go into command config mode via cmsh (get to ethernet portion of switch), show run, copy run etc will work in here.
    FCoE is default, FCoE has special vlan 1002 dedicated to it.
    switchport converged allow vlan all



    Cisco Terminal Server

    Cisco Terminal Server ref commands (aka Communitaion Server?)

    to dig out the online doc, go to section inside IOS
    (they don't have terminal server listed as its own section! A site map may help):

    -Cisco Product Documentation
    -Cisco IOS Software config
    -System Software Release 9.21 (or whatever newest number)
    -Then find secions called Communication Server ...
    (IOS 8.3 and 9.0 has it listed as Terminal Server)


    ---

    (machine at cc is cisco 2600 series, maybe 2621 (or 2632?)

    Connection to machine via terminal server:

    telnet axecess
    > telnet 2.2.2.2 2036

    or, for named connections, just enter telnet db03.
    other connection exist, like
    connect db03
    rlogin db03


    to disconnect from a 'telnet' session to a server, use:

            CTRL-6 x, then type 'disc' at the axecess prompt

    to generate a BREAK:

            CTRL-6 b


    other telnet escape seq inside the terminal server:
    first hit ctrl+shift+6  (ie ctrl+^),
    then enter ? for list of escape seq for the specific telnet session
    with the cisco terminal server.

    ---

    clearing existing connection (to free up for use again)

    axecess> enable
    password:
    axecess# clear line 36
    [confirm]

    (line 36 was the line of connector 1 line 4, listed as 2036)
    (add 2032 to the line cable number that want to connect)

    [ from joanne email
    really just 2000+ line number,
    but somehow internally already reserved 32 async lines.
    thus the module we add need 32 + cable number, prepended with 20 in front.
    connector 1 would be 2033 to 2040,
    connector 2 would be 2041 to 2048, etc



    (TBD: cisco*config sample config files after clean up and masking)

    Juniper

  • Port starts at 0 ?
  • Arista

  • arista command line very similar to cisco ios
  • port start at 1 (0 in cisco? or juniper?)


    show runing interface eth1
    show runing interface eth51/1	# sfp28 port (ib/100g) can be a break out into 4 port, thus the blade syntax
    show runing interface eth1,7	# port list  1 and  7
    show runing interface eth1-7	# port range 1 thru 7

    clear couter eth 30 		# reset counter for specific port (eg eth/30)

    switchport access vlan   # ie not tagged

    ! example of "traditional" network port for host without vlan tagging
    interface Ethernet4
       switchport access vlan 5
       spanning-tree portfast
    !



    ! example of network ports with vlan tag, also allow "untagged" as natively default to vlan 21
    interface Ethernet3
       switchport trunk native vlan 21
       switchport trunk allowed vlan 20-21
       switchport mode trunk
       spanning-tree portfast
    !

    # a switch to switch trunk would allow all vlan?

    ...


    int eth 29/1
      description "100G link to core switch"
      swich port mode trunk
      switchj port trunk allowed vlan add 1000
    end


    # create static route
    ip route 10.21.0.0/16 10.8.23.1
    ip route 10.22.0.0/16 10.8.23.1

    vlan 1000
      name bldg-A-to-bldg-B
    !
    end

    int vlan 1000
      desc bldg-A-to-bldg-B
      ip address 10.22.255.254/30
    end



    # brand new switch, disable zeroconfig
    zeroconf reset # or was it zeroconf clear ?  it reboots right away!


    # misc one time settings
    term length 50
    no log console		# disable sending log to the console

    # create admin acc so can ssh in
    username admin role network-admin secret sha512 $6$pl/qPWc8xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx.WI.kE.KXS5M7wsLubNZkBtC5nyj6ZF/S/LlUNeitL59I8KJ1









    show running-config > scp:tin@10.2.22.2/tmp/run.txt
    show startup-config > scp:tin@10.2.22.2/tmp/startup-config.txt


    <<**>> #### mask out the username ... sha  password entry near the beginning of the config file #### <<**>>

    copy run start	# or write mem

    Troubleshooting commands

    show interface status  # brief table view of port, desc, link status, vlan
    show interface status  | egrep Et[23]

    show mac address-table 				# arp table, vlan, mac, port
    show mac address-table interface eth 24     # mac of remote host on that switch port

    show mac  address-table | include Et3		# port 3
    show mac  address-table | include ac1f.6b	# search which port has a given mac

    # cycle a port
    config term
    interface ethernet 4
      shutdown
      no shutdown
      show active
    end


    # remember branding has to match!
    show int eth29/1 transceiver properties





    Foundry

    foundry network gear commands allegedly extremely similar to cisco, direct competitor thoug tab completion is not as nice as extreme net gears.

    load balancer:


    enable		= enter into priviledged (admin) mode.
    show config	= show configuration

    show version	= show sw and hw version
    show flash		= show firmware/image version number
    show tech		= pull all info that can possilbly have so that tech support has absolutely everything

    show interface ethernet 1 	= show eth1 info (duplex, utilization, collision, etc)
    show interface				= show all interface information

    ---

    change network mask to /24 bit (from /20)
    ie change ip from 172.16.0.5/20 to 172.16.0.5/24
    the ip is inside a vlan

    show vlan on the switch had:
    PORT-VLAN 361, Name [None], Priority level0, Spanning tree Off
     Untagged Ports: None
        Tagged Ports:  1  2 			! trunk port 1 and 2 into 2 GigE pipe
    	Uplink Ports: None


    config term
    	vlan 361		! specify the vlan of the network to be configured
    					! this case, 361 is for the vlan of 172.16.0.0
    	ip-subnet 172.16.0.0 255.255.255.0 name shared5-1
    	end
    					! note that no changes were done on Tagged, so old settings remain
    					! presumably, for tftp config image, better specify everything
    					! so as to not leave residue from previous config and get unexected result
    					! then again, tftp config should completely wipe out old setting.

    config term
    	ip address 172.16.0.5/24		! config ip and subnet of the load balancer itself
    	end

    write mem


    ---

    updating firmware (OS)

    login via serial (for later reboot monitoring)
    enter into enable mode

    backup running config (to tftp server):
    	copy running tftp ServerIP SavedFileName
    	eg: copy run tftp 10.0.1.103 nlb.cfg
    Note that cuz of permission problems, one may need to create a file (size 0) in the tftp
    server storage dir so that the uploaded file can be written to disk, and not get failure errors.

    actually get the image:
    	copy  tftp flash SvrIP FILENAME primary
    	eg: copy tftp flash 10.0.1.103 BSI07118T8.bin primary


    save old running config:
    	write memory

    reboot the load balancer for the new firmware/OS to kick in
    	reload

    verify version after reboot.
    	show ver

    ---
    copy cmd is of form [FROM] [TO] [additional params]

    ---

    # erase virutal server stuff
    # will see these info in 'show server bind'
    no server real
    no server virtual


    # erase ALL config!!
    erase start




    ----

    some additional cmds used in cifs but not documented.

    show server bind

    show server
    tcp-age
    sticky-age
    session-age

    server real
      no health check

    server virtual
      no port default translate
      no port default dsr   (direct server response)
      port default 5001



    Extreme Network



    telnet IP
    login...


    show config			= like cisco, config of the switch

    show port config	= show A=active, R=ready, 10/100 half/full/auto

    show port rxerrors  = show receive errors
    show port txerrors	= show transmit errors

    show port collisions


    config:
    config port 1:10 auto on						= autosensing config
    config port 1:10 auto off duplex full speed 100	= forced config

    port id of 1:10 is blade 1, port 10.  range can be specified as 1:10-1:20, or comma list as 1:10,1:15

    save config
    	save the configuration, so boot will come back to this state
    	option to save as primary.
    	(contrast to cisco write mem)


    show vlan			= list configured vlan
    show vlan 	= list ports used for the specified vlan


    show iparp		= show arp table
    show iparp  = detailed info about specific ip, arp level.

    show iproute
    	show ip routing info
    	  r = rip
    	  d = dynamic, from other router
    	  s = static

    show ipr IP / bitMask
    	show routing info of specific ip range
    	eg. 192.168.0.0 / 16 will be for all address starting 192.168.*.*,
    	even if no specific class B net defined

    show ipr stat	= show packet discard info per vlan

    show ipconfig	= ip config, some vlan info



    show flow-redirect
    	policy based flow control
        limit what source ip packets go to which output
    delete {flow}
    	remove a specific policy rule about flow control.

    show access-list
    	port blocking features, include ICMP and sub protocols
    delete {access-list}
    	remove a specific acl, eg deny-icmp,
    	which block certain traceroute info (extreme bug?).



    download image  file prim
    	should be the one to download a new os into the primary store.
    	ExtremeNet seems to support a secondary etc.
    	i guess bootable via alternate cmd.

    clear couter eth 30
    	reset counter for specific port (eg eth/30)
    clear couter
    	reset all counters (collision stats, etc)


    upload config tftpSvrIP Filename
    	save the configuration to the tftp server at IP with name filename
    	Note that tftp server may need to have the file with mode 666 to write.

    download config tftpSvrIP Filename
    	grab complete config for the switch from a file at the remote tftp svr.
    	(never tried)


    ---

    some brief notes when adding an ip to the switch, and upgrading the os via tftp.

    conf default de port 23
    create vlan temp
    conf temp ipaddr 172.16.17.50 /20
    conf temp add port 23
    en ipf temp

    --
    change the netmask of the switch (by specifiying the ip and new netmask bit numbers on the main vlan?
    Or, I suppose for each vlan, the switch has an IP, thus specify that IP and the netmask for it)

    conf shared5-1 ipaddress 172.16.0.1/24

    shared5-1 is the vlan name shown in show vlan
    /24 indicate a class C network, and system automatically convert to use the netmask of 255.255.255.0
    note that /20 would convert to netmask of 255.255.240.0


    ---

    trunking:
    	ports that are grouped together to form a trunk is called tagging in ExtremeNet.
    	Thus, a tag on port 1 and 2 would form a 2 GigE trunk


    ---



    configuring switch from ground up.
    this was done by jacinto for ngw1, i copy over, might have missed a few commands.

    # This will ERASE EVERYTHING on the config of the switch, and
    # reset to factory defaults.
    unconfigure switch all


    # do not use bootp, which may get ip, config, etc that we don't want
    disable bootp default

    config snmp sysName	ngw1-nsw1

    # create account for user admin
    config account admin

    # ngw1-1 is the primary vlan where all linux modules are in
    create vlan ngw1-1
    config ngw1-1 ipaddress 172.24.53.1/24
    config ngw1-1 add port 1:1-1:32
    enable ipf ngw1-1
    enable rip
    config rip add vlan ngw1-1

    # ??
    config rip txmode v1compatible vlan ngw1-1

    # this one assign a vlan id to the vlan ngw1-1.
    # will need to match on switch for them to actually talk correctly.
    config ngw1-1 tag 422

    # this is the vip for the load balancer
    create vlan ngw1-vip1
    config ngw1-vip1 ipaddress 192.168.214.1/24
    enable ipf ngw1-vip1
    config ngw1-vip1 tag 766
    enable rip ngw1

    # then are some port config tagging that i did not fully get.
    # port 3:1 is the uplink port (separate vlan)
    # port 3:2 is the load balancer
    # End result is:
    # ngw1-vip1 has 2 ports: untag: 3:1  tag: 3:2
    # ngw1-1 has ports 1:1 - 1:32 and tag 3:2

    config rip add ngw1-vip1
    config ngw1-1 add port 3:2
    config ngw1-vip2 add port 3:1



    ---

    loading new firmware to switch


    download image 10.0.1.80 FILENAME primary
    # also recommend download to secondary so it can boot in case of disaster

    can change use of primary or secondary by: use config ... (?)

    show ver


    ---

    blocking most of the ICMP access list in the cluster
    (needed to emulate production config, where gateway in compute modules dying will NOT send ICMP to client to reset NFS moutns).

    create access-list permit-icmp-vm1-1 icmp dest 172.24.67.0 /24 source any type 3 code 3 permit ports any precedence 10

    create access-list deny-icmp icmp dest any source any type 3 code 3 deny ports any precedence 100

    The precedence number is to sort how the switch analyzed these rules.
    lowest number = highest priority = applied first (#1).
    largest, last applied rule is #25600.

    The above eg, ICMP from outside to the internam machines are allowed.
    The next rule to be analyzed block all otherwise not specified ICMP to be blocked.
    Thus effectively blocking any ICMP originating from the cluster machine to the outside are blocked.
    I have no details of what kind of ICMP commands are in type 3 code 3.



    ---

    vlan tag stuff, self notes after layoff.

    config vlan
      add ip address
      add tag

      add port X tag
      add port y,z untag


    multiple vlan can use the same port as long as the port is added as tag.
    the tag will defferentiate the vlan.
    the peer router will have the port as multiple vlan also, and will therefore
    be able to route them as necessary.

    switch to switch vlan tag, then the port will just behave as if they were separate switch port.
    or think of port needing  to identify it into a vlan.

    in each subnet, only port that need to be shared with other subnet need to be tagged.
    port that goes to computer don't need to be tagged.
    note that if tag does not match peer switch/router, then there will be no traffic flowing thru them.




    Router

    FireWall

    PIX

    enable
    config terminal
    conduit permit tcp host 64.41.188.93 eq 22 host 65.5.190.138
    write memory
    exit

    (TBD, mask, clean up and combine ~/ref/pix.ref cc*)

    CheckPoint

    Check Point Firewall-1 commands:

    cplic print	# print licenses info (expiration, modules)

    fwinstall	# install check point fw s/w ??

    fw commands:
    fw ver [-h] ...                                 # Display version
    fw kill [-sig_no] procname                      # Send signal to a daemon
    fw putkey ...                                   # Client server keys
    fw sam ...                                      # Control sam server
    fw fetch targets                                # Fetch last policy
    fw tab [-h] ...                                 # Kernel tables content
    fw monitor [-h] ...                             # Monitor VPN-1/FW-1 traffic
    fw ctl [args]                                   # Control kernel
    fw lichosts                                     # Display protected hosts
    fw log [-h] ...                                 # Display logs
    fw logswitch [-h target] [+|-][oldlog]          # Create a new log file;
                                                    # the old log is moved
    fw repairlog ...                                # Log index recreation
    fw mergefiles ...                               # log files merger
    fw lslogs ...                                   # Remote machine log file list
    fw fetchlogs ...                                # Fetch logs from a remote host



    /etc/ipsoinfo		# get info for troubleshooting, save to tar.gz file




    # password recovery for Nokia IP120 (FreeBSD based).
    -s		# at boot prompt of Nokia IP120, boot into single user mode, no password
    /etc/overpw	# reset to temp password, eg to blank.
    dbpasswd admin newpassword ""		# reset network voyager password.


    Load Balancer

    ArrowPoint

    ArrowPoint ContentSwitch Load Balancer (Now part of Cisco CSM)


    Ref:
    ArrowPoint/Cisco
    Content Smart Web Switch
    Configuration Guide
    (700+ page doc Mike Kail printed from online doc)

    Adding user:
    (config)# username  password  {superuser}

    Add the keyword superuser at the end to indicate account can access priviledged sueruser commands.  (like the default admin account)

    Listing user:
    (config)# no username ?

    Note: default admin acc can be erased, but make sure has other user with superuser priviledges!

    Showing user info:
    (config)# show user-database

    Erasing user:

    no username

    ---

    Show runtime config, such as prompt, hostnae, ip, etc
    (config)# show running-config global

    ---

    Setting the hostname:
    host


    ---

    changing CLI prompt:
    prompt












    [Doc URL] tiny.cc/NETWORK
    https://tin6150.github.io/psg/tool.html
    http://tin6150.github.io/psg/net.html
    (cc) Tin Ho. See main page for copyright info.

    Valid CSS! Valid HTML 4.01 Strict


    hoti1
    "ting"
